Epoxy Fiberglass Roving Roll Corrosion Resistant Advanced Reinforcement Material

Name: Epoxy Fiberglass Roving Roll Corrosion Resistant Advanced Reinforcement Material
Brand: WGSC
Price: 0.42 USD

Quality Epoxy Fiberglass Roving Roll Corrosion Resistant Advanced Reinforcement Material wholesale

Certification : ISO9001

Place of Origin : CHINA

MOQ : 5000KGS

Payment Terms : T/T

Brand Name : WGSC

Price : $0.42-$1.13（KG）

Delivery Time : 3-7 work days

Supply Ability : 150000T/month

Packaging Details : Palletize

Linear Density (tex) : 1200-2400

Density Tolerance : ±5%

Compatible Resins : epoxy resin

Shape : FILAMENT WRAPPING

Chemical Resistance : Excellent

Contact Now

High Strength Epoxy Direct Roving Product Overview

Product Attributes

Attribute	Value
Linear Density (tex)	1200-2400
Density Tolerance	±5%
Compatible Resins	epoxy resin
Shape	FILAMENT WRAPPING
Chemical Resistance	Excellent
Corrosion Resistance	Excellent

Product Description

High-strength epoxy direct roving is manufactured with fluorine-free and boron-free glass technology, engineered specifically for epoxy resin systems using anhydride or amine curing agents. This advanced reinforcement material delivers exceptional performance in critical industrial applications.

Primary Applications

High-Pressure Piping Systems: Oil/gas transmission pipelines, chemical processing lines
Pressure Vessels: Gas storage tanks, reactor vessels, aerospace fuel containers
Electrical Insulation Components: High-voltage insulators, transformer bushings
Specialized Equipment: Wind turbine spar caps, ballistic armor panels

Technical Specifications & Performance Data

Key Performance Advantages

Property	Superior Performance	Testing Standard
Mechanical Strength	40%+ burst pressure resistance 3x fatigue life extension	ASTM D2290
Process Efficiency	30% faster resin wet-out vs. industry average	ISO 9163
Electrical Insulation	Volume resistivity >10¹⁵ Ω*cm	IEC 60250

Product Grades Table

Grade	Linear Density (tex)	Density Tolerance	Target Application
J201	1200-2400	±5%	High-pressure pipe winding
J206	1200-2400	±5%	Pressure vessel fabrication
J215	1200-2400	±5%	Electrical insulation parts
J215A	1200-2400	±5%	/aerospace components

Unified Certifications:
- ISO 2078 Class 1 compliance
- Sizing agent thermal stability: -40°C~180°C (ASTM D3039)

Advanced Packaging System

Multi-Level Protection

Packaging Tier	Technical Specification	Protection Class
Unit Packaging	PVC shrink film/PE adhesive film	IP67 moisture barrier
Pallet Matrix	4×4 configuration (48/64 rolls)	Anti-vibration design
Pallet Armoring	Corrugated top/bottom covers + side panels	≥800kgf compression resistance
Transport Security	Multi-layer stretch film wrapping	ISTA 3E certified

Scientifically Validated Storage Protocol

Environmental Control Parameters

Parameter	Optimal Range	Monitoring System
Temperature	15°C-35°C	Climate-controlled warehouse with auto-alert
Relative Humidity	30%-70%	Hygrometers + dehumidification units
Stacking Requirements	≥20cm floor clearance ≥50cm wall distance	Rack monitoring sensors

Quality Preservation Measures

36-month shelf life in original packaging
FIFO inventory management with laser tracking codes
Quarterly moisture testing (max 0.1% content)
